Gold ore, typically characterized by high hardness, strong abrasiveness, and high quartz content, places extreme demands on cone crusher wear parts—especially mantle (moving cone liner) and concave (fixed cone liner). Selecting the right material and matching crusher model directly impacts production efficiency, part service life, and operational costs.
With over 30 years of expertise in wear-resistant parts manufacturing, SHANVIM shares professional insights to help gold mining operations maximize performance.
Key Challenges of Gold Ore Crushing
Gold ore is among the most challenging materials for crushing:
High hardness: Compressive strength often exceeds 250 MPa, dominated by quartz and sulfide minerals.
Severe abrasion: High silica content accelerates wear on liners, increasing replacement frequency.
Impact loads: Irregular ore shapes and large feed sizes create repeated shock stress on mantle and concave.
Moisture & stickiness: Some gold deposits contain clay, leading to potential cavity blocking and uneven wear.
These challenges require wear parts with excellent work-hardening capacity, high toughness, and superior abrasion resistance—and crusher models with robust structure, large feed opening, and reliable hydraulic protection.
Best Material Choices for Mantle & Concave in Gold Ore
High-manganese steel remains the mainstream choice for cone crusher liners, as it work-hardens under impact while maintaining internal toughness. SHANVIM recommends three optimized grades for different gold ore conditions:
1. Mn18Cr2 (ZGMn18Cr2) – Universal Standard Grade
Composition: 17–19% Mn, 1.5–2.5% Cr, 1.1–1.4% C
Properties: As-cast hardness 200–240 HB; work-hardens to 450–550 HB under impact, balancing toughness and abrasion resistance
Application: Most gold ore scenarios (medium-hard, quartz-bearing, normal abrasion). Ideal for mid-size crushers in secondary/tertiary circuits—SHANVIM’s top-selling grade for gold mining clients.
2. Mn22Cr2 – High-Abrasion Upgrade Grade
Composition: 21–23% Mn, 2.0–3.0% Cr, 1.1–1.4% C
Properties: Higher initial hardness (220–250 HB) and work-hardened hardness (500–580 HB); superior resistance to high silica and heavy impact
Application: Hard quartz vein gold ore, high-abrasion deposits, and large-feed crushing. Service life is 20–30% longer than Mn18Cr2, making it cost-effective for high-intensity operations
3. Mn13Cr2 – Economic Grade for Soft-Medium Gold Ore
Composition: 12–14% Mn, 1.5–2.0% Cr, 0.9–1.3% C
Properties: Good toughness, lower cost, but 15–20% shorter life than Mn18Cr2
Application: Soft gold ore with low quartz/clay content and small-scale operations where cost is prioritized
Premium Upgrade: TiC/WC-Embedded High-Manganese Steel
For extreme abrasion (e.g., ultra-high quartz gold ore), SHANVIM offers titanium carbide (TiC) or tungsten carbide (WC) embedded liners. The hard alloy pillars in the manganese matrix resist wear, delivering 2–4x service life vs. standard Mn18Cr2—perfect for 24/7 high-throughput plants.
Optimal Cone Crusher Models for Gold Ore
Gold ore crushing typically uses secondary/tertiary cone crushers after primary jaw crushing. SHANVIM recommends models categorized by throughput and feed size, focusing on robust structure, large cavity, and hydraulic adjustment:
1. Medium-Size Models (200–400 t/h) – Most Popular for Gold Mines
Key specs: Feed size ≤220 mm, power 220–250 kW, medium/fine cavity options
Advantages: Compact, stable, easy maintenance; balanced feed handling and product gradation
Application: Small-to-medium gold mines, secondary crushing, and high quartz ore. SHANVIM’s best-matched model for global gold clients—compatible with standard Mn18Cr2 liners for maximum cost-performance
2. Large-Size Models (400–600 t/h) – High-Throughput Gold Operations
Key specs: Feed size ≤320 mm, power 315 kW, heavy-duty frame, enhanced hydraulic protection
Advantages: Larger feed opening, higher capacity, thicker liners for extended life; ideal for hard, coarse gold ore
Application: Large-scale gold mines, primary secondary crushing, and high-impact scenarios. Pair with Mn22Cr2 liners for optimal wear resistance
3. Small-Size Models (80–200 t/h) – Pilot/Small Gold Projects
Key specs: Feed size ≤140 mm, power 75–132 kW, single-cylinder hydraulic design
Advantages: Lightweight, flexible, easy to transport; low capital cost
Application: Small pilot plants, remote gold deposits, or tertiary fine crushing. Use Mn13Cr2 liners for economic efficiency
4. Ultra-Large Models (600+ t/h) – Mega Gold Mines
Key specs: Feed size ≤450 mm, power 400+ kW, multi-cylinder hydraulic system, advanced automation
Advantages: Unmatched throughput, precise discharge control, overload protection; minimizes downtime in continuous operations
Application: Super-large gold mines, high-volume processing lines. Combine with TiC-embedded liners for maximum service life.
SHANVIM’s Gold Ore Crushing Solution Summary
Medium-hard, normal abrasion gold ore: Recommended liner material Mn18Cr2 | Recommended crusher model Medium-size (200–400 t/h)
Hard quartz, high abrasion gold ore: Recommended liner material Mn22Cr2 | Recommended crusher model Large-size (400–600 t/h)
Soft, low quartz gold ore: Recommended liner material Mn13Cr2 | Recommended crusher model Small-size (80–200 t/h)
Ultra-high abrasion, 24/7 operation: Recommended liner material TiC/WC-embedded Mn18Cr2 | Recommended crusher model Ultra-large (600+ t/h)
Why Choose SHANVIM for Gold Ore Crushing Parts?
As a leading global supplier of wear parts with 30+ years of experience, SHANVIM delivers:
Premium materials: Strict quality control for Mn18Cr2/Mn22Cr2 and embedded alloys, ensuring consistent performance
Precision manufacturing: ISO 9001-certified production, perfect fit for all mainstream cone crusher models
Custom solutions: Tailored liner designs and material grades for specific gold ore conditions
Global support: Products exported to 30+ countries, with fast delivery and professional after-sales service
Conclusion
For gold ore crushing, Mn18Cr2 is the universal liner material, with Mn22Cr2 for high-abrasion scenarios and Mn13Cr2 for soft ore. Medium/large-size cone crushers are the mainstream choice, matching throughput to mine scale.
By partnering with SHANVIM, gold mining operations can reduce wear costs, extend part life, and boost overall profitability.
